05701-A-0330 H0NEYWELL Single Channel Control Card

Description

H0NEYWELL 05701-A-0330 Single Channel Control Card

DESCRIPTION

H0NEYWELL 05701-A-0330 is a single channel control card that is part of the Honeywell 5701 series control system.This control card is mainly used to monitor and control gas detectors installed in industrial environments,typically used to detect the concentration of harmful gases.It can receive signals from gas detectors and trigger alarms or take other control measures based on preset thresholds.

05701-A-0330 H0NEYWELL

Product parameters

Input signal:catalytic bridge or 4-20mA

Output signal:optional alarm relay output,optional 0-20mA or 4-20mA isolated monitoring output

Power supply voltage:18V to 32VDC

Power consumption:Catalytic type:3.75W(typical value),4-20mA:3.25W(typical value)

Display:Four part LCD display,including analog display,digital display,and information display

Alarm setting point resolution:1%FSD

Working temperature:-5°C to+55°C

Size:3U high x 25mm wide

Weight:165g

Certification:Compliant with EMC standards

Product specifications

Dimensions:17cm x 2.5cm x 11.2cm

Installation method:Can be installed in a standard 19 inch rack or a half 19 inch rack

series

The H0NEYWELL 05701-A-0330 control card belongs to the Honeywell 5701 series control system.This series of systems is designed to monitor industrial gas detectors installed on site,providing multiple configuration options to meet different application needs.

05701-A-0330 H0NEYWELL

characteristic

Single channel working mode:suitable for high integrity systems

Detachable control card:does not affect other wiring

Multiple input options:catalytic bridge or 4-20mA input

Multiple alarm modes:main alarm,partition alarm,and voting alarm

Configurability:Parameters can be configured through engineering cards,such as alarm updates,event printing,etc

Communication capability:optional Modbus protocol for serial communication

role

The main function of H0NEYWELL 05701-A-0330 control card is to:

Monitoring gas concentration:Receive signals from gas detectors and monitor gas concentration in real time

Trigger alarm:When the gas concentration exceeds the preset threshold,trigger the alarm

Control:Based on preset logic,control other devices such as fans,valves,etc

Display and recording:display gas concentration,record alarm events

purpose

H0NEYWELL 05701-A-0330 control card is widely used in various industrial places,such as:

Petrochemical industry:used for detecting flammable and explosive gases such as oil and natural gas

Metallurgy:used for detecting toxic and harmful gases

Chemical industry:used for detecting various chemical gases

Pharmaceutical:Used for detecting harmful gases in the production process of drugs

Environmental Protection:Used for monitoring ambient air quality

05701-A-0330 H0NEYWELL

application area

The application field of H0NEYWELL 05701-A-0330 control card is very extensive,involving almost all industrial sites that require gas detection.
