3500/22M BENTLY transient data interface module

Description

Details of the BENTLY 3500/22M transient Data interface module:

Product overview

The BENTLY 3500/22M Transient Data Interface(TDI)module is an integral part of the BENTLY NEVADA 3500 monitoring system.It is mainly used to connect the 3500 monitoring System and compatible software(such as System 1 condition monitoring and diagnosis software)to achieve data acquisition and communication functions.The 3500/22M module is capable of collecting steady-state and transient dynamic data,including waveform data,and transferring the data to the host software for analysis and processing over an Ethernet link.

3500/22M BENTLY

Product parameters and specifications

Model:3500/22M

Manufacturer:BENTLY NEVADA

Interface type:Ethernet interface(RJ-45 or Optical fiber)

Supported protocols:TCP/IP,UDP,etc

Data transfer rate:10/100 Mbps or 100/1000 Mbps

Installation mode:Plug-in installed in 3500 racks

series

The 3500/22M belongs to the BENTLY NEVADA 3500 monitoring system.The 3500 system is BENTLY NEVADA’s flagship product for the protection of large rotating machinery such as steam turbines,compressors,generators,and more.

3500/22M BENTLY

trait

Common characteristics of transient data interface modules include:

Data acquisition:Ability to capture steady state and transient dynamic data,including waveform data

High-speed communication:Data is transferred to the host software at high speed via an Ethernet link

Real-time:It can collect and transmit data in real time to meet the needs of equipment condition monitoring

High reliability:Industrial grade design to ensure stable operation in harsh environments

Easy to use:Usually has simple configuration and diagnostic functions

effect

The function of the transient data interface module is to connect the 3500 monitoring system and the host software to realize the data acquisition and communication functions.It transmits the data collected by the 3500 monitoring system to the host software for the user to analyze and diagnose.

use

Transient data interface modules are widely used in a variety of industrial applications requiring condition monitoring and protection,such as:

Power industry:Used to monitor the operating status of steam turbines,generators and other equipment

Petrochemical industry:used to monitor the operating status of compressors,pumps and other equipment

Metallurgical industry:used to monitor the operating status of fans,motors and other equipment

3500/22M BENTLY

Application field

The applications of transient data interface modules are very broad,involving almost all industries requiring equipment condition monitoring and protection,such as:

electricity

Petrochemical industry

metallurgy

Machine building

traffic
