ABB CI854AK01 3BSE030220R1 PROFIBUS-DP/V1 interface module

Product description

ABB CI854AK01 3BSE030220R1 is a communication interface module for industrial automation.It is mainly used to connect ABB’s S800 I/O system and PROFIBUS DP network to achieve data exchange and communication.This module is usually used as a PROFIBUS DP slave station,receiving instructions from the master station and returning data.

CI854AK01 3BSE030220R1 ABB

Product parameters and specifications

Model:CI854AK01 3BSE030220R1

Series:S800 I/O

Communication protocol:PROFIBUS DP-V1

Master/Slave mode:Slave station

Baud rate:9.6 kbps to 12 Mbps

Interface type:RS485

Connector type:9-pin D-sub

Redundancy:Supports redundancy of the primary station

Hot swap:Supported

Diagnostic function:Supported

Power supply:24V DC

Operating temperature:-20°C to 70°C

Product net depth/length:127.5 mm

Net height:186mm

Net width:59 mm

Weight:0.7kg

Protection level:IP20,prevent dust and moisture intrusion

series

The module belongs to the ABB S800 I/O system family.The S800 I/O is a distributed I/O system from ABB,featuring modular and flexible configuration,which is widely used in various industrial automation fields.

CI854AK01 3BSE030220R1 ABB

trait

Supports PROFIBUS DP-V1:Can communicate with other devices that support PROFIBUS DP-V1.

Use as a slave station:As a slave station in the PROFIBUS network,receiving instructions from the master station and returning data.

Support for master redundancy:Connect to redundant PROFIBUS DP masters to improve system reliability.

Hot swap:Allows module replacement while the system is running,facilitating maintenance.

With diagnostic function:can diagnose module and network faults,easy maintenance.

Compact structure:The module size is small and easy to install in the control cabinet.

Easy to use:with a simple configuration and debugging process,easy to use.

effect

ABB CI854AK01 3BSE030220R1 Communication interface module provides the following functions:

Connect to the PROFIBUS DP network:Connect the S800 I/O system to the PROFIBUS DP network for data exchange.

Data transmission:Transmission of data in the PROFIBUS network,including control instructions,sensor data,etc.

System Integration:Integrate the S800 I/O system into a larger automation control system.

use

ABB CI854AK01 3BSE030220R1 communication interface modules are widely used in various industrial automation fields,such as:

Manufacturing:Used in production line automation,robot control,etc.

Petrochemical:Used for process control,data acquisition,etc.

Power system:Used for substation automation,distribution network monitoring,etc.

CI854AK01 3BSE030220R1 ABB

Application field

ABB CI854AK01 3BSE030220R1 Communication interface module is used in the following areas:

Industrial automation

Process control

Electric power system

transportation

Building automation
