SCM-1 DEIF control module

Description

Description DEIF SCML-1 Control module

Product description

DEIF SCML-1 is a multifunctional module commonly used in power systems,especially for the control and protection of generator sets.It integrates synchronizer,generator circuit breaker control unit and multi-sensor function,which can realize automatic synchronization,grid-connection,disassembly of generator set,and measurement and monitoring of various electrical parameters.

SCM-1 DEIF

Product parameters and specifications

Model:SCM-1

Manufacturer:DEIF

Type:Synchronization/measurement module

Applicable object:generator set

Functions:synchronization,grid connection,disassembly,measurement,protection

Input signal:voltage,current,frequency,etc

Output signal:control signal,alarm signal,etc

Power supply voltage:24V DC

Operating temperature range:-20°C to+70°C

Installation method:panel installation or guide rail installation

series

The DEIF SCM-1 module may belong to DEIF’s AGC or PMC family.DEIF is a well-known brand in the field of power control,and its products are widely used in various generator set control and power system automation.

SCM-1 DEIF

trait

DEIF SCML-1 control modules typically have the following characteristics:

Integration:Synchronizer,circuit breaker control and multi-sensor functions are integrated to reduce the number of external devices.

Automation:It can realize the automatic synchronization,grid-connection and uncoupling of the generator set,and improve the operation efficiency.

Protection function:provides a variety of protection functions,such as overvoltage,undervoltage,overcurrent,short circuit,etc.,to ensure the safe operation of the generator set.

Communication function:Support a variety of communication protocols to facilitate communication and data exchange with other systems.

Easy to use:It is equipped with friendly operation interface and configuration software,which is convenient for users to set parameters and monitor.

effect

The main function of the DEIF SCM-1 control module is to realize the automatic synchronization,grid-connection and de-column control of the generator set,as well as the measurement and monitoring of various electrical parameters.

use

DEIF SCML-1 control modules are widely used in a variety of places requiring generator set control,such as:

Power station:used to control the grid connection and operation of large generator sets.

Industrial enterprises:for the control of self-contained power stations or backup power supplies.

Ship:Used for the control and management of Marine generator sets.

Offshore platform:Used for the control and monitoring of offshore platform generator sets.

SCM-1 DEIF

Application field

Application areas of the DEIF SCM-1 control module include:

Power industry:Used in various types of power plants and substations.

Industrial sector:Used in various types of factories and enterprises.

Marine industry:Used for all types of ships.

Offshore industry:Used for various types of offshore platforms.
